Installation of automatic cleaning equipment for broiler cages

Installation of automatic cleaning equipment for broiler cages


Broiler cage automatic decontamination equipment is an indispensable equipment for the use of broiler cage culture. Because the broiler cage culture is multi-layered, the high-level chicken manure cannot be used for artificial defecation, so the automatic decontamination machine (traction type) It is very convenient and fast, so how to install the automatic cleaning machine? What should I pay attention to when installing?



I. About the installation of automatic cleaning machine



1. When installing, the cement angle fixing device used by the main machine should be buried 50cm underground to prevent the pull out when the tension is too large;



2. The corner of the corner wheel is not too long, and the outer tangential line of the corner wheel coincides with the center line of the septic line, that is, the outer tangential line is placed at the center line of the septic line to prevent the slab from deviating during the process of clearing the faeces;



3. Before use, add gear oil or oil 1.5 liter through the oil filling port of the reducer, not too much or too little to avoid the heat of the reducer;



4. Keep the small hole on the large oil plug of the reducer at the oil filling port of the reducer unblocked during use (remove the small air plug on the big oil plug)



5, the manure usually requires a depth of 30 ~ 50cm.
